Flush-fit square aluminium downpipe systems
Sleek square aluminium downpipe system with concealed internal joints for modern building designs
• 72x72mm and 102x102mm square sizes
• Life expectancy of 50 years or more
• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting
• 19 standard colours and hundreds more available on request
• Compatible with Evolve and Aligator gutter ranges (gutter dependent)
Related Information
Product List
Downpipe 3m
To ensure your Alutec system achieves its 50 year life expectancy, don't forget to order Alutec Joint sealant and austenitic fixings. Go to Sundries, Tools & Accessories for a full listing
| Code | Size (mm) | Length (mm) | Dimensions (mm) |
|---|---|---|---|
| RJ313 | 72x72 | 3000 | A: 3000 x B: 30 |
| Code | Size (mm) | Length (mm) | Dimensions (mm) |
|---|---|---|---|
| RJ413 | 102x102 | 3000 | A: 3000 x B: 34 |
Internal pipe joint spigot
All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ320 | 72x72 | A: 62 |
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ420 | 102x102 | A: 70 |
Bend
All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ330 | 72x72 | A: 150 x B: 150 | 92.5 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ332 | 72x72 | A: 128 x B: 128 | 112.5 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ430 | 102x102 | A: 198 x B: 198 | 92.5 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ432 | 102x102 | A: 154 x B: 154 | 112.5 |
Branch
All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ342 | 72x72 | A: 260 x B: 127 x C: 154 | 112.5 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ442 | 102x102 | A: 280 x B: 112 x C: 190 | 112.5 |
Shoe
All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ350 | 72x72 | A: 96 x B: 160 | 120 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) |
|---|---|---|---|
| RJ450 | 102x102 | A: 130 x B: 202 | 120 |
Access pipe
All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ360 | 72x72 | A: 300 x B: 140 x C: 105 |
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ460 | 102x102 | A: 300 x B: 140 x C: 105 |
Pipe clip
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ380 | 72x72 | A: 103 x B: 128 x C: 25 |
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ480 | 102x102 | A: 134 x B: 159 x C: 25 |
Adjustable eaves offset
All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) | Angle (0) | A Min (mm) | A Max (mm) |
|---|---|---|---|---|---|
| RJ3925 | 72x72 | B: 75 x C: 60 | 112.5 | 75 | 250 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) | A Min (mm) | A Max (mm) |
|---|---|---|---|---|---|
| RJ3950 | 72x72 | B: 75 x C: 60 | 112.5 | 75 | 500 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) | A Min (mm) | A Max (mm) |
|---|---|---|---|---|---|
| RJ39100 | 72x72 | B: 75 x C: 60 | 112.5 | 75 | 1000 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) | A Min (mm) | A Max (mm) |
|---|---|---|---|---|---|
| RJ4925 | 102x102 | B: 83 x C: 60 | 112.5 | 109 | 250 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) | A Min (mm) | A Max (mm) |
|---|---|---|---|---|---|
| RJ4950 | 102x102 | B: 83 x C: 60 | 112.5 | 109 | 500 |
| Code | Size (mm) | Dimensions (mm) | Angle (0) | A Min (mm) | A Max (mm) |
|---|---|---|---|---|---|
| RJ49100 | 102x102 | B: 83 x C: 60 | 112.5 | 109 | 1000 |
Fixed wall offset
Fixed wall offsets available to order, call Marley Alutec for a quote
| Code |
|---|
| Fixed wall offset |
Drain connector (slip socket)
Adapts to 110mm Ø drain pipe socket. All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ370 | 72x72 | A: 85 x B: 85 x C: 65 x D: 41 x E: 30 |
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJ470 | 102x102 | A: 115 x B: 115 x C: 65 x D: 41 x E: 30 |
Rainwater diverter
All joints must be sealed using Alutec Joint sealant SC101
| Code | Size (mm) | Dimensions (mm) |
|---|---|---|
| RJD35 | 72x72 | A: 98 x B: 30 x C: 500 |
