Traditional Moulded Ogee Aluminium Guttering

Traditional Moulded Ogee gutter

Traditional Moulded Ogee gutter

(Select a different size )

A range of Moulded Ogee BS 8530:2010 traditional style bolted aluminium guttering systems for replacement of cast iron on period, listed or traditional style new builds, combining aluminium’s inherent benefits of longevity and low maintenance. Manufactured to original British Standard cast iron dimensions.

• Available in 3 sizes

• Ideal for small to large properties

Life expectancy of 50 years or more

• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting

Completely interchangeable with cast iron

• Flow rate of up to 5.5 l/s and 263m2 per downpipe

24 standard colours and hundreds more available on request

• Available in the popular Heritage Black finish, which accurately replicates the appearance of cast iron

Product List

Gutter 1.83m

  • Marley Alutec Traditional Moulded Ogee aluminium guttering GM506
  • Marley Alutec Traditional Moulded Ogee aluminium guttering system
  • Marley Alutec Traditional Moulded Ogee aluminum guttering cad file

To ensure your Marley Alutec system achieves its 50 year life expectancy, don't forget to order Marley Alutec Joint sealant and austenitic fixings. Go to Sundries, Tools & Accessories for a full listing

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
GM406 100x75 1830 A: 107 x B: 76 x C: 60

Union

  • Marley Alutec Traditional Moulded Ogee aluminium gutter union GM520

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
GM420 100x75 A: 92

Fascia bracket

  • Marley Alutec Traditional Moulded Ogee aluminium gutter fascia bracket GM580

Quantity

Add
Code Size (mm) Dimensions (mm)
GM480 100x75 A: 117 x B: 99 x C: 30 x D: 38

Direct fix bracket

  • Marley Alutec Traditional Moulded Ogee aluminium gutter Direct fix bracket GM581

Quantity

Add
Code Size (mm) Dimensions (mm)
GM481 100x75 A: 69 x B: 24 x C: 9

Angle

  • Marley Alutec Traditional Moulded Ogee aluminium gutter angle GM530
  • Marley Alutec Traditional Moulded Ogee aluminium gutter angle GM536

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
GM430 100x75 A: 127 x B: 183 90° Internal

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
GM431 100x75 A: 75 x B: 19 90° External

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
GM435 100x75 A: 60 x B: 119 135° Internal

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
GM436 100x75 A: 75 x B: 18 135° External

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
GM439 100x75 Non standard Non standard - available on request

Outlet

  • Marley Alutec Traditional Moulded Ogee aluminium gutter outelt GM523

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Description Size (mm) Dimensions (mm) Outlet Centre (mm)
GM422 63mm Ø pipe connection 100x75 A: 192 x B: 50 50

Quantity

Add
Code Description Size (mm) Dimensions (mm) Outlet Centre (mm)
GM423 76mm Ø pipe connection 100x75 A: 192 x B: 50 64

Quantity

Add
Code Description Size (mm) Dimensions (mm) Outlet Centre (mm)
GM425 72x72mm pipe connection 100x75 A: 192 x B: 58 41

Quantity

Add
Code Description Size (mm) Dimensions (mm) Outlet Centre (mm)
GM426 102x76mm pipe connection 100x75 A: 192 x B: 58 41

Stop end

  • Marley Alutec Traditional Moulded Ogee aluminium gutter stop end GM550
  • Marley Alutec Traditional Moulded Ogee aluminium gutter stop end GM555

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Description Size (mm) Dimensions (mm)
GM450 External left hand 100x75 A: 47

Quantity

Add
Code Description Size (mm) Dimensions (mm)
GM455 Internal right hand 100x75 A: 47

Fixed rafter arm

  • Marley Alutec Traditional Moulded Ogee aluminium gutter fixed rafter arm AM73

Quantity

Add
Code Description Size (mm) Dimensions (mm)
AM71 Side fix 100x75 A: 20 x B: 240

Quantity

Add
Code Description Size (mm) Dimensions (mm)
AM74 Top fix 100x75 A: 20 x B: 240

Rise & fall bracket

  • Marley Alutec Traditional Moulded Ogee aluminium gutter rise & fall bracket AM93

Quantity

Add
Code Size (mm) Dimensions (mm)
AM91 100x75 A: 360 x B: 125 x C: 80 x D: 168

Leafguard

  • Marley Alutec Traditional Moulded Ogee aluminium gutter leafguard SL114

Bare aluminium unpainted finish only

Quantity

Add
Code Size (mm) Dimensions (mm)
SL114 100x75 A: 1220
