Evolve Deepflow Aluminium Guttering

Evolve Deepflow aluminium guttering system

Evolve Deepflow aluminium guttering system

Specifically developed to meet the demands of both the building owner & installer. Evolve Deepflow aluminium guttering system combines all the benefits of marine grade aluminium guttering with installation which is as fast and easy as PVC gutters.

• 128 x 75mm Deepflow guttering system

• Ideal for medium to large properties

Life expectancy of 50 years or more

• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting

• Flow rate of up to 4.9 l/s and 232m2 per downpipe

24 standard colours and hundreds more available on request

• Available at a lower price in the popular Heritage Black finish, which accurately replicates the appearance of cast iron

• Compatible with 76mm circular downpipe systems

Compatible Downpipes

Product List

Gutter 3M

  • Marley Alutec Evolve Deepflow aluminium gutter GT513
  • Marley Alutec Evolve Deepflow aluminium gutter system
  • Marley Alutec Evolve Deepflow aluminium gutter GE513 cad file

To ensure your Marley Alutec system achieves its 50 year life expectancy, don't forget to order Marley Alutec Joint sealant and austenitic fixings. Go to Sundries, Tools & Accessories for a full listing

Quantity

Add
Code Length (mm) Dimensions (mm)
GE513 3000 A: 128 x B: 75

Union

  • Marley Alutec Evolve Deepflow aluminium gutter union GE520

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Dimensions (mm)
GE520 A: 86

Fascia Bracket

  • Marley Alutec Evolve Deepflow aluminium gutter fascia bracket GE580

Quantity

Add
Code Dimensions (mm)
GE580 A: 140 x B: 90 x C: 70 x D: 38

Angle

  • Marley Alutec Evolve Deepflow aluminium gutter angle GE532
  • Marley Alutec Evolve Deepflow aluminium gutter angle GE537

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Dimensions (mm) Angle (0)
GE532 A: 144 x B: 35 90

Quantity

Add
Code Dimensions (mm) Angle (0)
GE537 A: 65 x B: 35 135

Quantity

Add
Code Dimensions (mm) Angle (0)
GE539 Non standard Non standard - available on request

Outlet

  • Marley Alutec Evolve Deepflow aluminium gutter outlet GE523

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Description Dimensions (mm) Outlet Centre (mm)
GE523 76mm Ø pipe connection A: 214 x B: 150 x C: 85 70

Stop End

  • Marley Alutec Evolve Deepflow aluminium gutter stop end GE550
  • Marley Alutec Evolve Deepflow aluminium gutter stop end GE555

All joints must be sealed using Marley Alutec Joint sealant SC101

Quantity

Add
Code Description Dimensions (mm)
GE550 Internal - for capping off outlet and angles A: 35

Quantity

Add
Code Description Dimensions (mm)
GE555 External - for capping off gutter ends A: 39

Rafter Arm

  • Marley Alutec Evolve Deepflow aluminium gutter fixed rafter arm AE73 & AE76

Adjustable rafter arm available. Go to Sundries, tools and accessories for product listing

Quantity

Add
Code Description Dimensions (mm)
AE73 Side fix A: 20 x B: 233

Quantity

Add
Code Description Dimensions (mm)
AE76 Top fix A: 20 x B: 233

Rise & Fall Bracket

  • Marley Alutec Evolve Deepflow aluminium gutter rise & fall bracket AE93

Quantity

Add
Code Dimensions (mm)
AE93 A: 360 x B: 125 x C: 80 x D: 168

Leafguard

  • Marley Alutec Evolve Deepflow aluminium gutter leafguard SL75

Bare aluminium unpainted finish only

Quantity

Add
Code Dimensions (mm)
SL75 A: 1220
