Evoke coping Systems

Evoke composite aluminium coping system

Evoke composite aluminium coping system

  • Fast & simple installation - Our composite aluminium coping system is fast to position and fix, whilst on-site adjustments can be made easily with standard carpentry skills & tools
  • Wind loading - Tested by a UK based independent building research centre to withstand hurricane force winds of up to 176MPH
  • Weathertight butyl adhesive seal - Will maintain a 100% weathertight seal throughout its 50 year life expectancy and outlast EPDM compression seals normally used in coping systems
  • Nano self-cleaning paint finish to keep maintenance costs to a minimum
  • 10 standard colour options

Product List

Coping panel - 3m

  • Marley Alutec Evoke composite aluminium coping
  • Marley Alutec Evoke composite aluminium coping dimensions

Supplied with 2 Fixing brackets and required screws per 3m length. Please state precise wall width with estimate request or order. Composite aluminium coping cut to size by Marley Alutec to fit exact wall width. To set coping system to a fall of 2º or less, we recommend glazing shims supplied by others under each Fixing bracket. For falls greater than 2º, contact the Marley Alutec Technical Services Department.

Quantity

Add
Code Length (mm) Wall Width Ranges (mm)
N/A - Made to order 3000 Bespoke, cut to size to fit exact wall width

Angle 90º

  • Marley Alutec Evoke composite aluminium coping angle 90 degree

Supplied with 1 full Fixing bracket, 1 half Fixing bracket and required screws. Please state precise wall width with estimate request or order. Angle cut to size by Marley Alutec to fit exact wall width.

Quantity

Add
Code Description Wall Width Ranges (mm)
N/A - Made to order External Bespoke. cut to size to fit exact wall width

Quantity

Add
Code Description Wall Width Ranges (mm)
N/A - Made to order Internal Bespoke, cut to size to fit exact wall width

Stop end

  • Marley Alutec Evoke composite aluminium coping stop end

Supplied with 1 Fixing bracket and required screws. Please state precise wall width with estimate request or order. Stop end cut to size by Marley Alutec to fit exact wall width.

Quantity

Add
Code Description Wall Width Ranges (mm)
N/A - Made to order Left hand Bespoke, cut to size to fit exact wall width

Quantity

Add
Code Description Wall Width Ranges (mm)
N/A - Made to order Right hand Bespoke, cut to size to fit exact wall width

T-Junction 90º

  • Marley Alutec Evoke composite aluminium coping t-junction

Supplied with 2 Fixing brackets and required screws. Please state precise wall width with estimate request or order. T-Junction cut to size by Marley Alutec to fit exact wall width.

Quantity

Add
Code Wall Width Ranges (mm)
N/A - Made to order Bespoke, cut to size to fit exact wall width

Stop end upstand

  • Marley Alutec Evoke composite aluminium coping stop end upstand

Supplied with 1 Fixing bracket and required screws. Please state precise wall width with estimate request or order. Stop end upstand cut to size by Marley Alutec to fit exact wall width.

Quantity

Add
Code Description Wall Width Ranges (mm)
N/A - Made to order Left hand Bespoke, cut to size to fit exact wall width

Quantity

Add
Code Description Wall Width Ranges (mm)
N/A - Made to order Right hand Bespoke, cut to size to fit exact wall width

Fixing bracket

  • Marley Alutec Evoke composite aluminium coping fixing bracket

Supplied with required screws. Please state precise wall width with estimate request or order. Fixing bracket cut to size by Marley Alutec to fit exact wall width.

Quantity

Add
Code Wall Width Ranges (mm)
N/A - Made to order Bespoke, cut to size to fit exact wall width
