Traditional Rectangular Downpipe System

Traditional rectangular aluminium downpipe system

Traditional rectangular aluminium downpipe system

Cast socketed aluminium downpipe system suitable for both modern and traditional buildings

• 102x76mm size

Life expectancy of 50 years or more

65% lighter than cast iron, making it easier and safer to handle on site

• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting

24 standard colours and hundreds more available on request

• Compatible with Traditional and Aligator gutter ranges (gutter dependent)

Product List

Downpipe

  • Marley Alutec Traditional rectangular aluminium downpipe RSR113

To ensure your Alutec system achieves its 50 year life expectancy, don't forget to order Alutec Joint sealant and austenitic fixings. Go to Sundries, Tools & Accessories for a full listing. Add NE after product code for non eared pipe, i.e. RSR113NE

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RSR111 102x76 1000 A: 154 x B: 182 x C: 44

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RSR112 102x76 2000 A: 154 x B: 182 x C: 44

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RSR113 102x76 3000 A: 154 x B: 182 x C: 44

Pipe socket

  • Marley Alutec Traditional rectangular aluminium downpipe pipe socket RSR120

All joints must be sealed using Alutec Joint sealant SC101. Add NE after product code for non eared pipe, i.e. RSR120NE

Quantity

Add
Code Size (mm) Dimensions (mm)
RSR120 102x76 A: 80 x B: 87 x C: 112 x D: 40

Bend

  •  Marley Alutec Traditional rectangular aluminium downpipe bend RSR132

For 102x76mm size, Add R or L after product code if right or left hand projection is required, i.e. RSR130R. All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR130 102x76 A: 175 x B: 175 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR132 102x76 A: 63 x B: 140 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR135 102x76 A: 55 x B: 132 135

Branch

  • Marley Alutec Traditional rectangular aluminium downpipe branch RSR142

For 102x76mm size, Add R or L after product code if right or left hand projection is required, i.e. RSR140R. All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR140 102x76 A: 280 x B: 130 x C: 140 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR142 102x76 A: 280 x B: 112 x C: 156 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR145 102x76 A: 280 x B: 72 X C: 164 135

Shoe

  • Marley Alutec Traditional rectangular aluminium downpipe shoe RSR150

Add NE after product code for non eared pipe, i.e. RSR150NE. All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR150 102x76 A: 108 x B: 170 120

Access pipe

  • Marley Alutec Traditional rectangular aluminium downpipe access pipe RSR160

Add NE after product code for non eared pipe, i.e. RSR160NE. All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RSR160 102x76 A: 300 x B: 140 x C: 105

Pipe clip

  • Marley Alutec Traditional rectangular aluminium downpipe pipe clip RSR180

Quantity

Add
Code Size (mm) Dimensions (mm)
RSR180 102x76 A: 134 x B: 159 x C: 25

Fixed offset

  • Marley Alutec Traditional rectangular aluminium downpipe fixed offset RSR1906

Other offset projections available on request. For 102x76mm size, Add R or L after product code if right or left hand projection is required, i.e. RSR1903R. All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR1903 102x76 A: 75 x B: 82 x C: 160 x D: 60 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR1904 102x76 A: 100 x B: 82 x C: 175 x D: 60 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR1906 102x76 A: 150 x B: 82 x C: 185 x D: 60 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR1909 102x76 A: 225 x B: 82 x C: 210 x D: 60 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RSR1912 102x76 A: 300 x B: 82 x C: 245 x D: 60 112.5

Adjustable offset

  • Marley Alutec Traditional rectangular aluminium downpipe adjustable offset RSR1945

For 102x76mm size, Add R or L after product code if right or left hand projection is required, i.e. RSR1945R. All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RSR1945 102x76 B: 82 x C: 60 112.5 75 450

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RSR1990 102x76 B: 82 x C: 60 112.5 75 900

Drain connector (slip socket)

  • Marley Alutec Traditional rectangular aluminium downpipe drain connector RSR170

Adapts to 110mm Ø drain pipe socket

Quantity

Add
Code Size (mm) Dimensions (mm)
RSR170 102x76 A: 90 x B: 116 x C: 65 x D: 41 x E: 30

Rainwater diverter

  • Marley Alutec Traditional rectangular aluminium downpipe rainwater diverter RSRD15

Quantity

Add
Code Size (mm) Dimensions (mm)
RSRD15 102x76 A: 98 x B: 30 x C: 500

Hopper head (standard)

  • Marley Alutec Traditional rectangular aluminium downpipe hopper head RH105

Quantity

Add
Code Size (mm) Dimensions (mm)
RH105 102x76 A: 250 x B: 180 x C: 180 x D: 44

Hopper head (ornamental)

  • Marley Alutec Traditional rectangular aluminium downpipe hopper head RH305

Quantity

Add
Code Size (mm) Dimensions (mm)
RH305 102x76 A: 410 x B: 190 x C: 185 x D: 43
