Traditional Circular Downpipe Systems

Traditional circular aluminium downpipe systems

Traditional circular aluminium downpipe systems

Cast socketed aluminium downpipe systems suitable for both modern and traditional buildings

• 63mm, 76mm and 102mm circular sizes

Life expectancy of 50 years or more

65% lighter than cast iron, making it easier and safer to handle on site

• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting

24 standard colours and hundreds more available on request

• Compatible with Evolve, Traditional and Aligator gutter ranges

Product List

Downpipe

  • Marley Alutec Traditional circular aluminium downpipe RR313

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101. Add NE after product code for non eared pipe, i.e. RR313NE

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR211 63 1000 A: 110 x B: 143 x C: 59

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR212 63 2000 A: 110 x B: 143 x C: 59

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR213 63 3000 A: 110 x B: 143 x C: 59

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR311 76 1000 A: 109 x B: 160 x C: 70

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR312 76 2000 A: 109 x B: 160 x C: 70

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR313 76 3000 A: 109 x B: 160 x C: 70

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR411 102 1000 A: 153 x B: 185 x C: 91

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR412 102 2000 A: 153 x B: 185 x C: 91

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RR413 102 3000 A: 153 x B: 185 x C: 91

Pipe socket

  • Marley Alutec Traditional circular aluminium downpipe pipe socket RR320

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101. Add NE after product code for non eared pipe, i.e. RR320NE

Quantity

Add
Code Size (mm) Dimensions (mm)
RR220 63 A: 74 x B: 72 x C: 59 x D: 37

Quantity

Add
Code Size (mm) Dimensions (mm)
RR320 76 A: 83 x B: 85 x C: 70 x D: 37

Quantity

Add
Code Size (mm) Dimensions (mm)
RR420 102 A: 99 x B: 110 x C: 91 x D: 48

Bend

  • Marley Alutec Traditional circular aluminium downpipe bend RR332

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR230 63 A: 105 x B: 200 x C: 37 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR232 63 A: 100 x B: 220 x C: 37 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR235 63 A: 100 x B: 210 x C: 37 135

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR330 76 A: 110 x B: 220 x C: 42 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR332 76 A: 110 x B: 230 x C: 42 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR335 76 A: 90 x B: 245 x C: 42 135

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR430 102 A: 50 x B: 170 x C: 80 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR432 102 A: 50 x B: 235 x C: 80 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR435 102 A: 50 x B: 290 x C: 80 135

Branch

  • Marley Alutec Traditional circular aluminium downpipe branch RR342

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR240 63 A: 210 x B: 112 x C: 112 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR242 63 A: 210 x B: 90 x C: 140 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR245 63 A: 210 x B: 70 x C: 160 135

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR340 76 A: 250 x B: 138 x C: 112 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR342 76 A: 250 x B: 119 x C: 130 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR345 76 A: 250 x B: 65 x C: 180 135

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR440 102 A: 310 x B: 174 x C: 121 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR442 102 A: 310 x B: 150 x C: 150 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR445 102 A: 310 x B: 105 x C: 195 135

Shoe

  • Marley Alutec Traditional circular aluminium downpipe shoe RR350

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101. Add NE after product code for non eared pipe, i.e. RR350NE

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR250 63 A: 95 x B: 100 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR350 76 A: 103 x B: 124 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR450 102 A: 125 x B: 140 112.5

Access pipe

  • Marley Alutec Traditional circular aluminium downpipe access pipe RR360

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101. Add NE after product code for non eared pipe, i.e. RR360NE

Quantity

Add
Code Size (mm) Dimensions (mm)
RR260 63 A: 300 x B: 140 x C: 105

Quantity

Add
Code Size (mm) Dimensions (mm)
RR360 76 A: 300 x B: 140 x C: 105

Quantity

Add
Code Size (mm) Dimensions (mm)
RR460 102 A: 300 x B: 140 x C: 105

Pipe clip

  • Marley Alutec Traditional circular aluminium downpipe pipe clip RR380

Quantity

Add
Code Size (mm) Dimensions (mm)
RR280 63 A: 100 x B: 75 x C: 59

Quantity

Add
Code Size (mm) Dimensions (mm)
RR380 76 A: 98 x B: 72 x C: 70

Quantity

Add
Code Size (mm) Dimensions (mm)
RR480 102 A: 130 x B: 104 x C: 91

Fixed offset

  • Marley Alutec Traditional circular aluminium downpipe fixed offset RR3906

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101. Non standard projections available on request

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR2903 63 A: 75 x B: 65 x C: 300 x D: 160 154

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR2904 63 A: 100 x B: 45 x C: 330 x D: 120 149

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR2906 63 A: 150 x B: 60 x C: 360 x D: 120 140

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR2909 63 A: 225 x B: 50 x C: 345 x D: 85 126

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR2912 63 A: 300 x B: 35 x C: 365 x D: 90 120

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR3903 76 A: 75 x B: 55 x C: 345 x D: 115 154

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR3904 76 A: 100 x B: 55 x C: 365 x D: 115 149

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR3906 76 A: 150 x B: 55 x C: 395 x D: 115 140

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR3909 76 A: 225 x B: 45 x C: 410 x D: 115 126

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR3912 76 A: 300 x B: 45 x C: 420 x D: 110 120

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR4903 102 A: 75 x B: 15 x C: 255 x D: 64 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR4904 102 A: 100 x B: 15 x C: 265 x D: 64 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR4906 102 A: 150 x B: 15 x C: 280 x D: 64 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR4909 102 A: 225 x B: 15 x C: 305 x D: 64 112.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RR4912 102 A: 300 x B: 15 x C: 330 x D: 64 112.5

Adjustable offset

  • Marley Alutec Traditional circular aluminium downpipe adjustable offset RR3945

Joints must be sealed using Alutec Pipe socket filler SC911 and Joint sealant SC101. Non standard projections available on request

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RR2945 63 B: 50 x C: 90 112.5 150 450

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RR2990 63 B: 50 x C: 90 112.5 150 900

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RR3945 76 B: 48 x C: 163 112.5 200 450

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RR3990 76 B: 48 x C: 163 112.5 200 900

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RR4945 102 B: 15 x C: 64 112.5 110 450

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RR4990 102 B: 15 x C: 64 112.5 110 900

Rainwater diverter

  • Marley Alutec Traditional circular aluminium downpipe rainwater diverter RRD35

Quantity

Add
Code Size (mm) Dimensions (mm)
RRD25 63 A: 150 x B: 500 x C: 79 x D: 25

Quantity

Add
Code Size (mm) Dimensions (mm)
RRD35 76 A: 150 x B: 500 x C: 79 x D: 25

Pipe socket filler

  • Marley Alutec Traditional circular aluminium downpipe pipe socket filler SC911

Caulking foam for sealing Traditional circular sockets

Quantity

Add
Code Description
SC911 Foam, 10m roll

Hopper head (standard)

  • Marley Alutec Traditional circular aluminium downpipe hopper head RH102

Quantity

Add
Code Size (mm) Dimensions (mm)
RH101 63 A: 250 x B: 180 x C: 180 x D: 58

Quantity

Add
Code Size (mm) Dimensions (mm)
RH102 76 A: 250 x B: 180 x C: 180 x D: 70

Quantity

Add
Code Size (mm) Dimensions (mm)
RH103 102 A: 250 x B: 180 x C: 180 x D: 91

Hopper head (fluted)

  • Circular aluminium downpipe hopper head fluted RH402

Quantity

Add
Code Size (mm) Dimensions (mm)
RH401 63 A: 285 x B: 210 x C: 225 x D: 59 x E: 18

Quantity

Add
Code Size (mm) Dimensions (mm)
RH402 76 A: 285 x B: 210 x C: 225 x D: 70 x E: 18

Hopper head (ornamental)

  • Marley Alutec Traditional circular aluminium downpipe hopper head ornamental RH302

Quantity

Add
Code Size (mm) Dimensions (mm)
RH301 63 A: 410 x B: 190 x C: 185 x D: 59

Quantity

Add
Code Size (mm) Dimensions (mm)
RH302 76 A: 410 x B: 190 x C: 185 x D: 70

Quantity

Add
Code Size (mm) Dimensions (mm)
RH303 102 A: 410 x B: 190 x C: 185 x D: 91
Requirements List
Requirements List

Add product qty and all relevant information to your requirement list ready to send for an estimate

Request an Estimate Remove All
