Flush-fit rectangular aluminium downpipe system

Flush-fit rectangular aluminium downpipe system

Sleek rectangular downpipe system with concealed internal joints for modern building designs

• 102x76mm rectangular size

Life expectancy of 50 years or more

• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting

24 standard colours and hundreds more available on request

• Compatible with the Aligator gutter range (gutter dependent)

Product List

Downpipe 3m

  • Marley Alutec Flush-fit rectangular aluminium downpipe RJ113

Quantity

Add
Code Size (mm) Length (mm) Dimensions (mm)
RJ113 102x76 3000 A: 3000 x B: 34

Internal pipe joint spigot

  • Marley Alutec Flush-fit rectangular aluminium downpipe pipe joint spigot RJ120

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RJ120 102x76 A: 70

Bend

  • Marley Alutec Flush-fit rectangular aluminium downpipe bend RJ130

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RJ130 102x76 A: 175 x B: 175 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RJ132 102x76 A: 150 x B: 150 112.5

Branch

  • Marley Alutec Flush-fit rectangular aluminium downpipe Branch RJ142

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RJ142 102x76 A: 280 x B: 112 x C: 190 112.5

Shoe

  • Marley Alutec Flush-fit rectangular aluminium downpipe shoe RJ150

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RJ150 102x76 A: 104 x B: 187 120

Access pipe

  • Marley Alutec Flush-fit rectangular aluminium downpipe access pipe RJ160

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RJ160 102x76 A: 300 x B: 140 x C: 105

Pipe clip

  • Marley Alutec Flush-fit rectangular aluminium downpipe pipe clip RJ180

Quantity

Add
Code Size (mm) Dimensions (mm)
RJ180 102x76 A: 134 x B: 159 x C: 25

Adjustable eaves offset

  • Marley Alutec Flush-fit rectangular aluminium downpipe adjustable eaves offset RJ1925

Other offset projections available on request. For 102x76mm size, Add R or L after product code if right or left hand projection is required, i.e. RJ1925R. All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RJ1925 102x76 B: 83 x C: 60 112.5 75 250

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RJ1950 102x76 B: 83 x C: 60 112.5 75 500

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0) A Min (mm) A Max (mm)
RJ19100 102x76 B: 83 x C: 60 112.5 75 1000

Drain connector (slip socket)

  • Marley Alutec Flush-fit rectangular aluminium downpipe drain connector RJ170

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RJ170 102x76 A: 90 x B: 116 x C: 65 x D: 41 x E: 30

Rainwater diverter

  • Marley Alutec Flush-fit rectangular aluminium downpipe rainwater diverter RJD15

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RJD15 102x76 A: 98 x B: 30 x C: 500

Hopper head (standard)

  • Marley Alutec Flush-fit rectangular aluminium downpipe hopper head RH115

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RH115 102x76 A: 250 x B: 180 x C: 180 x D: 44
