Aligator Classic Square Downpipe system

Aligator Classic square aluminium downpipe system

Aligator Classic square aluminium downpipe system

A 62x62mm square downpipe system for use with the Aligator Classic Ogee gutter

• Ideal for small to large properties

• Flow rate of up to 4.1 l/s and 196m2 per downpipe

Life expectancy of 50 years or more

• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting

24 standard colours and hundreds more available on request

• Available at a lower price in the popular Heritage Black finish, which accurately replicates the appearance of cast iron

Product List

Downpipe 3m

  • Marley Alutec Aligator Classic square aluminium downpipe RK313

To ensure your Alutec system achieves its 50 year life expectancy, don't forget to order Alutec Joint sealant and austenitic fixings. Go to Sundries, Tools & Accessories for a full listing

Quantity

Add
Code Size (mm) Length (mm)
RK313 62x62 3000

Pipe socket

  • Marley Alutec Aligator Classic square aluminium downpipe pipe socket eared RK320

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Description Size (mm) Dimensions (mm)
RK320 Eared 62x62 A: 97 x B: 119 x C: 87 x D: 45

Quantity

Add
Code Description Size (mm) Dimensions (mm)
RK320NE Non Eared 62x62 C: 87 x D: 45

Bend

  • Marley Alutec Aligator Classic square aluminium downpipe bend RK332

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK330 62x62 A: 105 x B: 115 92.5

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK332 62x62 A: 54 x B: 45 112.5

Branch

  • Marley Alutec Aligator square aluminium downpipe branch RK342

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK342 62x62 A: 165 x B: 80 x C: 95 112.5

Shoe

  • Marley Alutec Aligator square aluminium downpipe shoe RK350

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK350 62x62 A: 85 x B: 176 120

Access pipe

  • Marley Alutec Aligator circular aluminium downpipe access pipe RK360

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RK360 62x62 A: 210 x B: 120 x C: 55

Pipe clip

  • Marley Alutec Aligator Classic square aluminium downpipe pipe clip RK380

Quantity

Add
Code Size (mm) Dimensions (mm)
RK380 62x62 A: 105 x B: 129 x C: 25

Wall offset

  • Marley Alutec Aligator Classic square aluminium downpipe wall offset RK3902

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK3902 62x62 A: 95 x B: 70 X C: 50 135

Rainwater diverter

  • Marley Alutec Aligator Classic square aluminium downpipe rainwater diverter RK25B

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Description Size (mm) Dimensions (mm)
RK25B Only available in PVCu 62x62 A: 87 x B: 18 x C: 500

Hopper head (standard)

  • Marley Alutec Aligator Classic square aluminium downpipe hopper head RH100

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RH100 62x62 A: 250 x B: 180 x C: 180 x D: 36
Requirements List
Requirements List

Add product qty and all relevant information to your requirement list ready to send for an estimate

Request an Estimate Remove All
