Aligator Classic Circular Downpipe System

Aligator Classic circular aluminium downpipe system

Aligator Classic circular aluminium downpipe system

A 63mm aluminium circular downpipe system for use with the Aligator Classic Ogee gutter

• Ideal for small to large properties

• Flow rate of up to 4.1 l/s and 196m2 per downpipe

Life expectancy of 50 years or more

• Marine grade aluminium throughout. Highly corrosion resistant, it will never rust or need repainting

24 standard colours and hundreds more available on request

• Available at a lower price in the popular Heritage Black finish, which accurately replicates the appearance of cast iron

Product List

Downpipe 3m

  • Marley Alutec Aligator circular aluminium downpipe RK213

To ensure your Alutec system achieves its 50 year life expectancy, don't forget to order Alutec Joint sealant and austenitic fixings. Go to Sundries, Tools & Accessories for a full listing

Quantity

Add
Code Size (mm) Length (mm)
RK213 63 3000

Pipe socket

  • Marley Alutec Aligator circular aluminium downpipe pipe socket eared RK220
  • Marley Alutec Aligator circular aluminium downpipe pipe socket non eared RK220NE

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Description Size (mm) Dimensions (mm)
RK220 Eared 63 A: 82 x B: 52 x C: 94 x D: 116 x E: 59

Quantity

Add
Code Description Size (mm) Dimensions (mm)
RK220NE Non Eared 63 A: 82 x B: 52

Top bend

  • Marley Alutec Aligator circular aluminium downpipe top bend RK232

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK232 63 A: 50 x B: 35 x C: 46 112.5

Bottom bend

  • Marley Alutec Aligator circular aluminium downpipe bottom bend RK292

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK292 63 A: 40 x B: 64 x C: 40 112.5

Bend

  • Marley Alutec Aligator circular aluminium downpipe bend RK230

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK230 63 A: 37 x B: 27 x C: 46 92.5

Branch

  • Marley Alutec Aligator circular aluminium downpipe branch RK242

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK242 63 A: 95 x B: 26 x C: 115 112.5

Shoe

  • Marley Alutec Aligator circular aluminium downpipe shoe RK250

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm) Angle (0)
RK250 63 A: 92 x B: 104 120

Access pipe

  • Marley Alutec Aligator circular aluminium downpipe access pipe RK260

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RK260 63 A: 300 x B: 140 x C: 105

Pipe clip

  • Marley Alutec Aligator circular aluminium downpipe pipe clip RK280

Quantity

Add
Name Code Size (mm) Dimensions (mm)
RK280 RK280 63 A: 94 x B: 118 x C: 59

Rainwater diverter

  • Marley Alutec Aligator circular aluminium downpipe rainwater diverter RKD25

All joints must be sealed using Alutec Joint sealant SC101

Quantity

Add
Code Size (mm) Dimensions (mm)
RKD25 63 A: 134 x B: 500 x C: 74 x D: 30

Hopper head (standard)

  • Marley Alutec Aligator circular aluminium downpipe hopper head RH110

Aligator Classic 63mm downpipe compatible with Hopper Head RH110

Quantity

Add
Code Size (mm) Dimensions (mm)
RH110 63 A: 250 x B: 180 x C: 180 x D: 59
